Specification:
Width 375
Operating temperature (T-T) -10 - 55
Mobile operating systems supported Android,iOS
Output voltage 12
Processor cores 4
Built-in processor Y
Product colour Black
RS-232 interface Y
Alarm output channels 2
Alarm input channels 4
Backup function Y
Brand compatibility Any brand
Rack capacity 1U
Rack mounting Y
Snapshot Y
PTZ control Y
Operating system installed Embedded Linux
On Screen Display (OSD) Y
Video loss detection Y
Number of motion detection zones 396
Video motion detection Y
Two-way talk Y
Number of users 128
Bit rate 20000
Maximum resolution 3840 x 2160
Video input channels 8
Playback modes Backup selection,Digital zoom,Forward,Full screen,Next camera,Pause,Play,Previous camera,Repeat,Reverse,Shuffle,Speed Adjust,Stop
Playback controls Y
Audio RCA outputs 1
Audio RCA inputs 1
VGA (D-Sub) output ports 1
HDMI ports quantity 1
HDMI output Y
Ethernet LAN data rates 10,100,1000
Ethernet LAN (RJ-45) ports 1
Number of HDDs supported 2
Recording time 120
Recording modes Manual,Schedule,Stop
Split screen Y
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 1
Throughput data rate 320
Maximum storage capacity 24
Power over Ethernet (PoE) N
USB 2.0 ports quantity 1
Supported network protocols HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP
Power consumption (typical) 9.5
Operating relative humidity (H-H) 10 - 90
Depth 282
Height 56
Weight 1600
Output current 4
Video formats supported H.264,H.265,M-JPEG,MPEG4
Supported resolutions 3840 x 2160, 1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Compatible products Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek
