Fujitsu ScanPartner SP-1130N 30ppm / 60ipm A4 Duplex ADF LED Office Scanner

Fujitsu ScanPartner SP-1130N 30ppm / 60ipm A4 duplex ADF Gigabit Ethernet USB 3.2 LED Office Scanner, Automatic Document feeder, Duplex, Single line cmos-cis x 2 (Image sensor Type, RGB LED x 2 light source, 600 dpi optical Resolution, 4500 sheets expected daily Volume, 50 sheets ADF capacity, Overlap detection (Ultrasonic sensor), USB 3.2 Gen 1x1 / USB 2.0 / USB 1.1, 10Base-T / 100Base-TX / 1000Base-T Ethernet

Overview:

Simple and network compatible scanner for business
The SP-1130N provides high-value performance as an entry-level model for your business with scanning speeds of 30 ppm/60 ipm (A4 portrait, color, 200 / 300 dpi), ADF capacity of 50 sheets, ability to scan a wide range of documents.

Supports both USB 3.2 Gen 1x1 high-speed connection and wired network connection
Compact and user-friendly design
High quality technologies for accurate and reliable feeding
Plastic card scanning
Comes with PaperStream IP and PaperStream Capture providing advanced image processing functions
Various software available for better data management
PaperStream ClickScan also available for ad-hoc use to scan in 3 simple steps
Features:

Easy scanning and operation relieves stress
A compact footprint allows the SP-1130N to be placed in locations with space restrictions. And even with its compact body, the scanner supports both USB 3.2 Gen 1x1 high-speed connection and wired network connection are supported, so that it can be used not only near the computer but also in various places under the network environment.

Simple and easy-to-use operation
Operation is also simple with only two button to push, Scan/Stop and Power On/Off. Its minimal design reduces risk of human error.

Reliability of accurate feed and protect documents - Reliable scanning
The SP-1130N stable scanning with 30 ppm scanning that does not drop speed even when scanning 300 dpi resolution and ADF that holds up to 50 sheets at a time. It assists stress-free and stable operation at the office for maximized precision and efficiency.

Accurate feeding ability for various documents
The scanner handles a wide range of paper from thin to thick, as well as plastic cards to suit all scanning needs. Operators need not worry about unexpected interruptions, rescans, or damaged documents.

Advanced software for higher productivity - Connect business workflow with PaperStream IP and PaperStream Capture
The PaperStream IP scanner driver, supporting both TWAIN/ISIS, eliminates the need of making fine setting adjustments for OCR processes. It automatically converts images into exceptionally clean images, accelerating OCR even when scanning wrinkled, soiled and patterned documents. With an intuitive interface, PaperStream Capture allows users to feed information into their organization's workflow through various capture features during batch scanning effectively and efficiently.

Searchable documents made possible with ABBYY FineReader Sprint
With ABBYY FineReader Sprint, scanned data can be converted to searchable PDF or office documents such as Word/Excel so that users can fully utilize the data in day to day work tasks.

Specifications:

Scanner Type
Scanner Type ADF (Automatic Document Feeder), Duplex
Scanning Speed (A4 Portrait)
Scanning Speed (A4 Portrait) Simplex: 30 ppm (200/300 dpi)
(Color/Grayscale/Monochrome)
(Color/Grayscale/Monochrome) Duplex: 60 ipm (200/300 dpi)
Image Sensor Type
Image Sensor Type Single line CMOS-CIS x 2 (front x 1, back x 1)
Light Source
Light Source RGB LED x 2 (front x 1, back x 1)
Optical Resolution
Optical Resolution 600 dpi
Output Resolution
Output Resolution (Color / Grayscale / Monochrome) 50 to 600 dpi (adjustable by 1 dpi increments), 1,200 dpi (driver)
Output Format
Output Format Color: 24-bit, Grayscale: 8-bit, Monochrome: 1-bit
Background Colors
Background Colors White
Document Size
Maximum 216 x 355.6 mm (8.5 x 14 in.)
Minimum 52 x 74 mm (2.0 x 2.9 in.)
Long Page Scanning 3,048 mm (120 in.)
Paper Weight (Thickness)
Paper 50 to 209 g/m (13.4 to 56 lb)
Plastic Card 0.76 mm (0.0299 in.) or less
ADF Capacity
ADF Capacity 50 sheets (A4 80 g/m or Letter 20 lb)
Expected Daily Volume
Expected Daily Volume 4,500 sheets
Multifeed Detection
Multifeed Detection Overlap detection (Ultrasonic sensor)
Interface
USB USB 3.2 Gen 1x1 / USB 2.0 / USB 1.1
Ethernet 10BASE-T, 100BASE-TX, 1000BASE-T
Power Requirements
Power Requirements AC 100 to 240 V ±10 %
Power Consumption
Operating Mode 18 W or less
Power Saving Mode 2 W or less
Auto Standby (Off) Mode 0.3 W or less
Operating Environment
Temperature 5 to 35 °C (41 to 95 °F)
Relative Humidity 20 to 80% (non-condensing)
Environmental Compliance
Environmental Compliance ENERGY STAR, RoHS
Dimensions (W x D x H)
Dimensions (W x D x H) 298 x 135 x 133 mm (11.7 x 5.3 x 5.2 in.)
Weight
Weight 2.5 kg (5.5 lb)
Supported Operating System
Supported Operating System Windows 10, Windows 8.1, Windows 7, Windows Server 2022, Windows Server 2019, Windows Server 2016, Windows Server 2012 R2, Windows Server 2012, Windows Server 2008 R2, macOS, Linux (Ubuntu)
Included Software / Drivers
Included Software / Drivers PaperStream IP for SP Series (TWAIN/TWAIN x64/ISIS), WIA Driver, Image Scanner Driver for macOS (ICA), Image Scanner Driver for Linux (SANE), PaperStream Capture, PaperStream ClickScan, Software Operation Panel, Error Recovery Guide, ABBYY FineReader for ScanSnap, Scanner Central Admin, ABBYY FineReader Sprint, Network Setup Tool for SP Series, SP Series Online Update
Image Processing Functions
Image Processing Functions Multi image output, Automatic color detection, Automatic page size detection, Blank page detection, Dynamic threshold (iDTC), Advanced DTC, SDTC, Error diffusion, Dither, De-Screen, Emphasis, Dropout color (None / Red / Green / Blue / White / Saturation / Custom), sRGB output, Split image, De-Skew, Edge filler, Vertical streaks reduction, Digital endorser, Background pattern removal, Character thickness, Character augmentation, Character extraction
Included Items
Included Items AC adapter, USB cable, Setup DVD-ROM
