HDMI Extender Over LAN 150m

HDMI EXTENDER OVER LAN 150M - HDME150M

HDMI KVM Extender Transmitter + Receiver Kit (Up to 150m)

Over Single Cat5e/6 Cable Bidirectional IR USB Keyboard Mouse

Transmission Distance: up to 200m over a single CAT6 cable, 150m over CAT5e cable

Video resolution: Up to 480P, 720P, 1920 x 1080 @ 30Hz,1920 x 1080 @ 60Hz

Audio Sampling Rate: 32kHz, 44.1kHz, and 48kHz

Audio Format: DTS-HD / Dolby-true HD / LPCM7.1 / DTS/DSD

USB KVM Function: Support Keyboard and Mouse remote control

HDMI Loop out The transmitter with one HDMI local output

H.264 compressed Technology, less than 50ms delay

Male To Male: One TX to one RX application

Male To Female: TCP / IP, one TX to N RX (Max:253 pcs RX) application with Ethernet switch / Router

IEEE-568B:standard 802.3 Ethernet 10/ 100/ 1000Mbps

Video Standard: compliance with HDMI 1.3 and HDCP 1.2 standard
