General Data
��� Pure Sine Wave Output
��� Multi Input: Solar PV, Generator & AC
��� Additional Battery Input Port
Inverter
��� Built In Battery: 1 x 100AH 12V
��� Rated Power: 1000W
��� Output Voltage: 220VAC
��� Output Frequency: 50Hz / 60Hz
��� Output Waveform: Pure Sine Wave
��� 2 x 3Pin SA Plug Output Sockets
Mains Input
��� Rated Voltage: 220VAC
��� Maximum Rated Charge Current: 10A
Solar Input
��� Maximum PV Voltage: =25V
��� Charge Voltage: 10VDC-25VDC
��� Rated Charge Current: 30A
��� Maximum Power: 360Wp
DC Output
��� 2 x 5VDC USB Output Ports (Max 2A)
��� 1 x 12VDC Output Port (Max 2A)
Environment Limit
��� Humidity: 0% to 90% (Non Condensing)
��� Operating Temperature Range: 0°C to +40°C
��� Storage Temperature: -25°C to +50°C
