RS232 Setup Recommendation
Scan the RS232 setup
Default:baud rate 9600?data bit 8?stop bit 1 ?no parity bit
To use RS232 mode ,the RS232 cable is needed to connect to the DB9 port of the device with the power
Specification
Electrical parameter 5/3.3V+10% x 100mA (idle: 10mA
Scanning type bi-directional
CPU ARM 32- bit Cortex
Version NO MJ_tech V3.00
Light source 650 nm visual laser diode
Trigger Mode handheld, Continuous, Auto-Induction
Auto-Induction interval time 0.3S
Handheld /Auto-Induction switching time 6S
Indication Buzzer & Indicator lamp Printing Contract >25%
Decoding speed 200scans/sec Resolution 3.3mil
Bit error rate 1/5million, 1/20million Scanning width 30cm
Depth of Field
3.3mil 2mm-100mm
10mil 2mm-350mm
15.6mil 5mm- 600mm
35mil 10mm-1000mm
Scanning angle:rotor angel??30??,inclination?? 45??,declination ?? 60??
Anti inference:industrial lighting or sun will not make any difference
Decoding Capability:UPC/EAN?with complementary UPC/EAN?Code128?Code39?Code 39Full ASCII?Coda bar?industrial /Interleaved 2 of 5?Code93?MSI?Code11?ISBN?ISSN?China post?etc
Button life :500,000 times ; laser life:10000 hours
Drop test :1.5m fall to concrete
Interface : TTL?RS232?KBW?USB
Certificate :CE,FCC,RoHS, Class I
