Samsung 55 inch Video Wall Display - Full HD

VM55B-U - Ultra Narrow Bezel LCD Video Wall for Business
• 3.5mm (B-to-B) ultra-narrow bezel video wall allows seamless display.
• The exceptionally thin cabinet depth provides flexibility to create the exact video wall.
• Non-glare panels evenly distribute light across the screen to maintain vibrant and accurate content.

Specifications:

55"
Screen Size
1920x1080
Resolution
500 nit
Brightness
24/7
Operation Hours
3.5mm
Bezel to Bezel
YES
Non Glare
HIDE ALL SPECS
Series Name
Series Name

VMB-U Series 55"

Display
Type

IPS

Screen Size
55"

Resolution
1920x1080

Pixel Pitch

0.63x0.63

Active Display Area

1209.6(H) x 680.4(V)

Aspect Ratio

16:9

Brightness

500 nit

Contrast Ratio (Typical)

1200:1

Operation Hours

24/7

Color Gamut

72

Haze

25%

Orientation

Landscape / Portrait

Bezel to Bezel

3.5mm

Non Glare

YES

Connectivity
Input

Video: HDMI 2.0 (2) / DVI-D, Display Port 1.2
Audio: Stereo mini Jack
USB: 2.0 x 1

Output

Video: DP1.2 (Loop-out)
Audio: Stereo mini Jack

External Control

RS23C(in/out), RJ45 in

Power
Power Supply

AC 100 - 240 V, 50/60 Hz

Power Consumption (Typical/Max)

Max: 220
Typical: 165
Sleep Mode: less than 0.5W

Environmental Conditions
Operating Temperature
0?~ 40?

Operating Humidity

10~80%

Features
Special

HARDWARE: Temperature Sensor, Video Wall Daisy Chain(10x10), DP 1.2 Digital Daisy Chain(Supporting UHD Resolution, HDCP support), Clock Battery(168hrs Clock Keeping)
SOFTWARE: Auto Source Switching & Recovery, RS232C/RJ45 MDC, Button Lock, Smart F/W update

24/7 Operation

Yes

System On Chip

Yes

Dimensions
Bezel Width (mm)

2.25mm(U/L), 1.25mm(R/B)

Without Stand (W x H x D)

1213.5 x 684.3 x 73.13

Packaging (W x H x D)

1398 x 844 x 257

Weight
Product Weight

19.4kg

Package Weight

27.6kg

Accessories
Included in Box

Quick Setup Guide
Warranty Card
Power Cord
RS232C(IN) Gender (Stereo to DB-9)
Remote Controller + Batteries
DP cable

Optional Wall Mount Kit

WMN-55VD

Mechanical Specs
VESA Mount

600 x 400

Certification
Safety

60950-1

EMC

Class A

IP Rating

IP5x
