Synology HAT5300-16T 16TB 3.5'' 7200rpm SATA 6Gb/s 512MB Cache Enterprise Hard Disk Drive, 262 MiB/s Maximum sustained Data transfer speed
Overview:
Enterprise storage drives for Synology systems
Synology HAT5300 HDD offers class-leading performance thanks to tight integration with DSM and Synology hardware. With over 300,000 hours of in-house validation testing, the HAT5300 series brings unmatched reliability to Synology deployments. Read the story behind it
Performance
Up to 274 MB/s sustained data transfer
Optimization
Up to 23% faster sequential read in Synology NAS
Reliability
Purpose-built for Synology servers running 24/7
Updates
Automatic firmware updates with DSM
Features:
Consistent performance scaling
Through testing and optimizations, HAT5300 series HDD has been tuned to deliver up to 23% higher sustained sequential read performance in demanding multi-user environments.
Rigorous validation
Over 300,000 hours of stress testing with Synology devices ensure that HAT5300 drives can withstand even the most demanding enterprise environments and deliver highly reliable performance.
Cumulative testing Stress tests
Effortless firmware updates
Automatic firmware updates through DSM mean that HAT5300 drives always benefit from the latest enhancements.
Durability for 24/7 environments
HAT5300 series HDD is backed by a 2.5 million hour MTTF rating, workload support of 550 TB per year, and persistent write cache technology to minimize data corruption in the event of sudden power loss.
Specifications:
Hardware Specifications HAT5300-16T
General
Capacity 16 TB
Form Factor 3.5"
Interface SATA 6 Gb/s
Sector Size 512e
Performance
Rotational Speed 7,200 rpm
Interface Speed 6.0 Gb/s, 3.0 Gb/s, 1.5 Gb/s
Buffer Size 512 MiB
Maximum Sustained Data Transfer Speed (Typ.) 262 MiB/s
Reliability
Mean Time to Failure (MTTF) 2.5 million hours
Workload Rating 550 TB Transferred per Year
Power Consumption
Supply Voltage 12 V (± 10%) / 5 V (+10/-7%)
Active Idle (Typ.) 4.00 W
Random Read / Write (4KB Q1) (Typ.) 7.63 W
Temperature
Operating 5°C to 60°C (41°F to 140°F)
Non-operating -40°C to 70°C (-40°F to 158°F)
Shock
Operating 686 m/s {70 G} (2 ms duration)
Non-operating 2,450 m/s {250 G} (2 ms duration)
Vibration
Operating 7.35 m/s {0.75 G} (5 to 300Hz), 2.45 m/s {0.25 G} (300 to 500 Hz)
Non-operating 29.4 m/s {3.0 G} (5 to 500 Hz)
Altitude
Operating -305 m to 3,048 m
Non-operating -305 m to 12,192 m
Relative Humidity
Operating 5% to 90% R.H. (No condensation)
Non-operating 5% to 95% R.H. (No condensation)
Others
Size (Height x Width x Depth) 26.1 mm x 101.85 mm x 147 mm
Weight 720 g
Certification CE
EAC
BSMI
RCM
KC
RoHS
ICES
TUV
UL
Compatibility
Applied Models HAT5300-8T
HAT5300-12T
HAT5300-16T
