TP-Link Archer AX20 AX1500 Wi-Fi 6 Router
|Networking Device Type||Wireless Routers|
TP-Link Archer AX20 AX1500 Wi-Fi 6 Router, Broadcom 1.5GHz Tri-Core CPU, 1201Mbps at 5GHz+300Mbps at 2.4GHz, 5 Gigabit Ports, 4 Antennas, Downlink and Uplink OFDMA, MU-MIMO, 1024QAM, Smart Connect, Beamforming, IPTV, Access Point Mode, VPN Server, IPv6 Ready, Tether
The Wi-Fi 6 Experience
The latest generation of WiFi technology brings faster speeds, less lag, and higher capacity, enabling more simultaneous connections on your home network.
Dual-Band Wi-Fi 6 Up to 1.8 Gbps
Every application feels more fluid with drastically improved WiFi speeds. Both 2.4 GHz band and 5 GHz band get upgraded to the latest generation—perfect for 4K streaming, online gaming, and fast downloading.
Extensive WiFi Coverage with Advanced Technologies
Beamforming technology, independent Front-End Module, and four high-gain antennas combine to adapt WiFi coverage to perfectly fit your home and concentrate signal strength towards your devices.
Connect More, Stay Fast
Easily handle dozens of devices streaming and gaming at the same time—OFDMA future-proofs your home networks by providing greater capacity to connect more devices.
OFDMA separates a single spectrum into multiple units and enables different devices to share one transmission stream, increasing efficiency and reducing latency.
Powerful Processing for Minimal Latency
A powerful 1.5 GHz quad-core CPU generates minimal latency within your network even under heavy load of transmission. Experience a faster response time for every website click or online video playback.
Easy File Sharing
Share music, movies, and documents easily on every device across your home network.
Full Gigabit Ports
Connect to your devices using a wired network for robust stability.
WPA3—New Level of Cyber Security
The latest WiFi security protocol, WPA3, brings new capabilities to improve cybersecurity in personal networks. More secure encryption in WiFi password safety and enhanced protection against brute-force attacks combine to safeguard your home WiFi.
Easily Setup and Manage WiFi with the Tether App
Set up your WiFi through the TP-Link Tether app in minutes. Manage network with versatile tools provided by TP-Link HomeCare™ Pro including QoS, online time limits, antivirus, and more.
Processor 1.5 GHz Quad-Core CPU
Interface 1x 1000/100/10 Mbps WAN Port
4x 1000/100/10 Mbps LAN Ports
1x USB 2.0 Port
Button WPS/Wi-Fi On/Off Button
Power On/Off Button
LED On/Off Button
External Power Supply 12 V / 1.5 A
Dimensions ( W x D x H ) 10.2 x 5.3 x1.5 in. (260.2 x 135.0 x 38.6 mm)
Antenna 4x Fixed Omni-Directional Antennas
Wireless Standards Wi-Fi 6
IEEE 802.11ax/ac/n/a 5 GHz
IEEE 802.11ax/n/b/g 2.4 GHz
Frequency 5 GHz
Signal Rate 1201 Mbps (5 GHz)
574 Mbps (2.4 GHz)
Compatible with 802.11a/b/g/n/ac Wi-Fi standards
Transmit Power FCC:<30dBm(2.4 GHz & 5.15 GHz~5.825 GHz)
Wireless Functions Enable/Disable Wireless Radio, DFS(JP Version Only), Guest Network, MU-MIMO, OFDMA
Wireless Security WPA
WAN Type Dynamic IP/Static IP/PPPoE
Management Parental Control
DHCP Server, DHCP Client List, Address Reservation
Dynamic DNS DynDns, NO-IP, TP-Link
Guest Network 2.4 GHz guest network x 1
5 GHz guest network x 1
NAT Port Forwarding, Port Triggering, UPnP, DMZ
Certification FCC, RoHS
Package Contents Wireless Router Archer AX20
RJ45 Ethernet Cable
Quick Installation Guide
System Requirements Microsoft Windows 98SE/NT/2000/XP/Vista /7/8/8.1/10, MAC OS
NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other
Cable or DSL Modem
Subscription with an internet service provider (for internet access)
