Ubiquiti's Rocket 2AC features revolutionary airPrism RF filtering technology and proprietary airMAX ac chipset. Deploy the Rocket 2AC for PtP or PtMP links using the 2.4 GHz radio band.
The Rocket 2ac features a new, high-performance airMAX 2GHz ac radio and airPrism technologies for maximum wireless performance in high-density areas. Pair the Rocket 2ac with airMAX antennas for optimal performance: RocketDish™ ac Antenna for a PtP backhaul or an airMAX ac Sector for PtMP links. It delivers coverage of the 2 GHz spectrum between 2412MHz - 2472MHz with a single radio. The Rocket2ac Prism allows for flexibility in configuring channel bandwidths (subject to regulations). The Rocket2ac is compatible with the AIR-O210, AIR-O213 and the AIR-S215.
Integrated into Ubiquiti’s custom silicon, airPrism technology creates a high SNR by isolating signals within the operating channel and rejecting interference using specialised circuitry, the High-Selectivity Receiver (HSR)
Specifications
Antenna Gain: Antenna Dependant (2x RP SMA Female)
Beam-width: Antenna Dependant
Data Rate: 600Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8.5W
Mounting: Pole-Mount
Operating System: airMAX ac
Operating Temperature: -40°C to 70°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V 0.5A Gigabit PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 18V-26V
USB Ports: None
Dimensions: 88 x 40 x 230mm
Weight: 440g
