Ubiquiti airFiber5X HD PtP Radio Gigabit WiFi | AF-5XHD

In stock
SKU
AF-5XHD
Special Price R 8,963.00 Regular Price R 13,791.00
  • Brands - Cliqtosave Online: Ubiquiti

Ubiquiti's AF-5XHD is designed for use in the 5GHz frequency band. It offers channel bandwidth of up to 100MHz, GPS synchronization and uses airOS LTU, manageable via UNMS. The AF-5XHD is designed to work with slant-polarized antennas for improved noise immunity and signal-to-noise ratio but is also compatible with other dish antennas in the Ubiquiti range. *Note: The AF-5XHD is not backwards compatible with the AF5X

More Information
BrandUbiquiti
Networking Device TypeWireless Adapters

Details

Ubiquiti's AF-5XHD is designed for use in the 5GHz frequency band. It offers channel bandwidth of up to 100MHz, GPS synchronization and uses airOS LTU, manageable via UNMS. The AF-5XHD is designed to work with slant-polarized antennas for improved noise immunity and signal-to-noise ratio but is also compatible with other dish antennas in the Ubiquiti range. *Note: The AF-5XHD is not backwards compatible with the AF5X


Specifications

Antenna Gain: Antenna Dependant (2x RP SMA Female)

Beam-width: Antenna Dependant

Data Rate: 1.34 Gbps

Ethernet Ports: Data - 1x 10/100/1000 ; Management – 10/100/1000

Hardware Button: Reset

Interfaces: 1

Max. Power Consumption: 6W-12W

Mounting: Antenna or Pole-Mount

Operating System: airOS F (airFiber)

Operating Temperature: -40°C to 55°C

PoE Input: 24V Passive PoE

PoE Output: None

Power Input: 24V, 1A Gigabit PoE Injector (Included)

Serial Interface: Bluetooth V4.0

SIM Slots: None

Supported Voltage Range: 18V-54V

USB Ports: None


Dimensions: 224 x 82 x 48mm

Weight: 0.35kg
