Unbranded Solar PV DC Circuit breaker (Isolator) 4 Pole 1000V 63A

Unbranded Solar PV DC Circuit breaker (Isolator) 4 pole 1000V 63A, Installation Isolator Ex9IP 4P 63A

Overview:

101765 Installation isolator Ex9IP 4P 63A
Installation switches Ex9IP find their application in photovoltaic and general DC systems, where is required only switch off function. They are offered in versions with rated current up to 63A and and rated voltage to 1000 V DC. These isolators can be supplemented with a wide range of accessories identical with circuit breakers Ex9B (except Ex9LE RCD add-on blocks). E.g. undervoltage release UVT can be used for safety disconnection of panels from the rest of the installation.

Specifications:

PAREMETER VALUE
Short-circuit breaking capacity (Icw) 0.76
Degree of protection (IP) IP20
Width in number of modular spacings 4
Built-in depth 79.5
Switching function Off switch
Number of change-over contacts 0
Rated switching capacity 1.26
Number of normally closed contacts 0
Nominal rated current 63
With signal lamp NO
Number of normally open contacts 4
Colour calotte Grey
Voltage type DC
Forced segregation (according to DIN VDE 0113) YES
Number of poles 4
Nominal rated voltage 1000
